Model C 35T DMA Card
$139.95
Xilinx® 7 series Artix-7 35T FPGA
- This advanced chip offers enhanced capacity and capabilities, delivering exceptional performance-per-watt efficiency, unmatched transceiver line rates, robust DSP processing, and refined AMS integration. Tailored for next-level applications, the 35T DMA card is the ideal choice for projects requiring higher logic density and increased processing power.
PCILeech Friendly
- 64-bit Memory Access, PCIe TLP access, and PCILeech compatible. PCILeech utilizes the PCIe board with FPGA DMA to read and write to the target system memory. Note: our card does not come with any custom firmware.
USB-C 3.2 FTDI FT601 Connection
- Experience lightning-fast data transfer with a USB 3.2 connection that effectively prevents bottlenecking during your operations. PCILeech DMA read/write speeds of up to 250 MB/s.
USB-C JTAG
-
With the On-Board JTAG, you can easily flash your 35t DMA card with just a USB connection from the Update Port. This eliminates the need for complicated JTAG cables, saving both time and effort
Kill Switch
- You can deactivate your card using the built-in on and off switch, eliminating the need to physically disconnect the device from your PC when you are not using the device.
USB Installation Drive
- Included in the packaging is a USB drive that contains all necessary drivers, tools, and detailed instructions to facilitate your initial installation process.
3 Month Warranty
- For specifics of how our warranties work please see here.
Comes with
1X USB-C TO USB-A 3.2 CABLE
1x Support Card
1x Installation Flash Drive
DMA Card Comparison Table
Environment for test:
PC1 – Windows 10, AMD Ryzen 7 1700x CPU, B450 Tomahawk Max II Motherboard, 16gb Ram, DMA installed into PCI_E5 (auto link speed)
PC2 – Windows 11, Beelink S12 Pro Mini PC, Amazon link
USB Cable – Packing included cable
| DMA Card | Avg Read Speed (of 5) | Avg Read Throughput (of 5) | JTAG Driver |
|---|---|---|---|
| Model U 75T | 6083 /second | 197.54 MB/s | CH347 |
| Model C 35T | 5581 /second | 198.31 MB/s | CH347 |
Hardware Install
Turn off your main PC and disconnect the power cable. On the motherboard of the PC that you wish to read the memory of (main PC), locate the farthest PCIe slot away from the primary GPU slot. Alternatively, you can use the primary GPU slot itself. For this block of instruction we are going to use the furthest slot.
Install the DMA card into the PCIe slot like pictured
